Thiết bị chuyển đổi VGA và âm thanh sang HDMI. AV access CV-V2H, plug and Play, tai gắn cố định
- Hỗ trợ đầu vào VGA đến đầu ra HDMI với âm thanh stereo
- Độ phân giải lên đến 1920×1200@60Hz và 1080P
- Chuyển đổi tín hiệu và âm thanh tương tự VGA
- Cắm và chạy với Fix EDID
The CV-V2H is a VGA to HDMI converter which transmits VGA and stereo audio signal from PC to monitors via VGA & Audio cable to HDMI display devices. This converter can be powered by computer via Micro USB cable.
Features of CV-V2H VGA & Audio to HDMI Converter
- Metal converter transmits VGA and stereo audio signal to HDMI output
- More suitable for installation requirement
- VGA resolution up to 1920×1200@60Hz
- Supports fixed EDID mode
- Supports stereo audio input
- Superior ESD protection
VGA + Stereo Audio to HDMI Converter
The converter supports video resolution up to 1920×1200@60Hz and 1080P; it also supports VGA input cable up to 5m and HDMI output cable up to 10m.
Mini Size & Great Performance
The converter can transmit VGA and stereo audio signal from your notebook, computer or set-top box to any HDMI display device. It can easily be powered by computer via Micro USB cable, saving you the hassles of using an extra power cable.
Diagram of CV-V2H VGA & Audio to HDMI Converter
Specification of CV-V2H VGA & Audio to HDMI Converter
| Technical | |
|---|---|
| I / O Connections | 1 x VGA IN 1 x Audio IN 1 x Micro USB Power Supply 1 x HDMI OUT |
| Input / Output Signal Type | HDMI1.4 |
| VGA Input Resolution | 640 x 480@60Hz, 800 x 600@60Hz, 1024 x 768@60Hz, 1280 x 720@60Hz, 1280 x 768@60Hz,1280 x 800@60Hz, 1280 x 1024@60Hz, 1360 x 768@60Hz, 1366 x 768@60Hz, 1400 x 1050@60Hz, 1440 x 900@60Hz, 1600 x 1200@60Hz, 1680 x 1050@60Hz, 1920 x 1080@60Hz, 1920 x 1200@60Hz |
| Supported Audio Format | Stereo Audio |
| Transmission | Supports up to 15m HDMI cable for HDMI OUT |
| Power Supply | USB 5V/0.5A, Micro USB Power Supply |
| Power Consumption | 1.5 Watts (Maximum) |
| Color | Black |
| General | |
|---|---|
| Operating Temperature | 32°F to 113°F (0°C to 45°C) |
| Storage Temperature | -4°F to 158°F (-20°C to 70°C) |
| Throughout | 10% to 90%, non-condensing |
| Humidity | WEP, TKIP, AES, WPA, WPA2 |
| Dimensions | 76.8mm × 64.2mm × 20mm/3.02’’ × 2.53’’ × 0.79’’ |
| Weight | 0.13kg/0.29lb |
